Product Description
Features
1. Wide temperature range,high effciency,enhaced vapor injection compressor;
2. High energy display control,high precision configuration,efficient heat recovery;
3. Modular stitching,transport,installation and removal are easier and more efficient.;
4. Environmentally friendly,energy saving,saving time;
5. The drying parameters are easy to control and wide adjustable range,drying quality is good;
6. Reasonable structure design: site survey, scientific planning, optimize investment costs, to ensure drying quality; easy installation and maintenance, smooth operation, easy to use;
7. Automatic temperature control,safe and environment protection.
This form is for reference only. We provide customized solutions based on customer's parameter requirements, providing each customer with one-to-one, more accurate parameter tables.
Heat pump closed belt modular sludge drying system | ||||||||
Model | HT-20IIJ4dZ | HT-25IIJ5dZ | HT-40IIJ4dZ | HT-50IIJ5dZ | HT-80IIJ4dZ | HT-100IIJ4dZ | HT-100IIJ4dZ*2 | HT-100IIJ4dZ*3 |
Water removed rate kg/24h | 480 | 600 | 960 | 1200 | 1920 | 2400 | 4800 | 7200 |
Water removed capacity kg/h | 20 | 25 | 40 | 50 | 80 | 100 | 200 | 300 |
Operating power kw | 6 | 8 | 12 | 14 | 23 | 26 | 52 | 78 |
Heating pump modular qty | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 3 |
Compressor qty | 1 | 1 | 1 | 1 | 4 | 4 | 8 | 12 |
Cooling type | air cooled | water cooled | air cooled | water cooled | air cooled | water cooled ( air cooled optional) | ||
Cooling water flow (15℃ temp difference) | // | 0.3 | // | 0.6 | // | 1.5 | 3 | 4.5 |
Refrigerant | R134a | |||||||
Power supply | 380V/3P/50HZ | |||||||
Dry temperature | 48~56℃ ( air back) 65~80℃ (air outlet) | |||||||
Control system | Touch screen + micro computer | |||||||
Wet mud usable range | Moisture content (40%~82%) ( different adaptation) | |||||||
Dry material water content | Inverter adjust, moisture content (10%~60%) | |||||||
Molding method | slitter and strip | |||||||
Dimension L (mm) | 1300 | 1300 | 1700 | 1700 | 2700 | 2700 | 5400 | 8100 |
Dimension W (mm) | 1400 | 1400 | 1700 | 1700 | 1200 | 1200 | 1200 | 1200 |
Dimension H (mm) | 2400 | 2100 | 2700 | 2300 | 2420 | 1680 | 1680 | 1680 |
Structure type | assemble | whole set | assemble | whole set | assemble | whole set | assemble | assemble |
Weight (kg) | 720 | 720 | 980 | 980 | 1600 | 1600 | 3200 | 4800 |
